LX circulatory pump for whirlpools EA320, 0.75 HP
Code: 01.05.01.0108Related products
Product detailed description
The LX circulation pump EA320 has a robust aluminum body, quality bearings and sealed parts for watertightness. It is very quiet even during continuous operation.
- Designed for optimal performance and flow
- Suction and return diameter 1 '' 1/2 (48 mm) for increased performance and reduced noise
- Engine cooling standard IPX5 for progressive temperature rise
- Thermal overheating detector to maintain and extend engine life
- Equipped with condenser (allows starting / lowering of pumps)
- Material adapted for whirlpools and swimming pools
Dimensions:
Length: 380 mm
Width: 160 mm
Height: 205 mm
Specifications:
Power: 0.75 HP (0.55 kW)
Current: 3.2A
Voltage: 230V / 50Hz
Maximum flow: 280 liters / min
The pump is supplied with flanges and o-rings for 1.5 "pipes.
Replaced by EA350.
Electrical connection:
Supplied with AMP PLUG cable.
Additional parameters
| Category: | Cirkulační čerpadla LX |
|---|---|
| Weight: | 9 kg |
| Brand: | LX |
| Type of pump: | Circulation |
| Output: | 0,5kW - 0,99kW |
| Hose inlet: | 48 - 59 mm |
| Hose outlet: | 48 - 59 mm |
| Model: | LX EA320 |
| Napětí: | 220-240V/50Hz |
| Izolační třída: | F |
| Krytí: | IPX5 |
| Maximální průtok: | 280 l/min |
| Maximální výtlačná výška: | 11 |
